CRDP2 Marine Constant Heating Cable
Products Visitors:352
Products description:


Product Name: CRDP2 Marine Constant Power Parallel Electric & Heating Cable

General Description: Marine Electric & Heating cable mainly used in ships,offshore drilling platform,pump body and so on,under the bad environment of explosive gas.Marine elecctricity cable besides all characteristics of RDP type electric heating and have good anti-corrosion,prevent mould to grow,salt fog resistance and oil mist,bibration,impact resistant,flame retardant features,which is applicable to may used a temperature classes T1-T4 group of two area sites with explosie air mixture,explosion-proof grade for ExIIT4,it’s on the basis of RDP type electric heating with advanced technology and strict quality assurance system to manufacture high quality products.

Application: Tilts: horizontal 22.5°,vertical 10°;Ship in the normal operation of a vibration and impact;Wet air,salt mist,oil mist and mold;No direct impact force;Minimum bending radius should not less than six times the thickness of electric & heating cable;Voltage and frequency deviation rating swings +6% to -10% and +6% respectively.


Model

Rated Voltage(V)

Rated Power W/m

Bidirectional Max. Length m

Highest

Heat

Explosion-proof grade EX

Insulation Resistance

CRDP2-20

220

20

380

205

eT3-T6

50MΩ

CRDP2-25

220

25

340

205

eT3-T6

50MΩ

CRDP2-30

220

30

300

205

eT3-T6

50MΩ

CRDP2-35

220

35

280

205

eT3-T6

50MΩ

CRDP2-40

220

40

260

205

eT3-T6

50MΩ

CRDP2-45

220

45

240

205

eT3-T6

50MΩ
